1030

DIMM

slot

cover

For

access,

remove

this

FRU:

v

Note:

Loosen

the

screws

1

,

but

do

not

remove

them.

1

2

1040

DIMM

For

access,

remove

these

FRUs

in

order:

v

v

1

1

2

When

installing:

Insert

the

notched

end

of

the

DIMM

into

the

socket.

Press

the

DIMM

firmly,

and

pivot

it

until

it

snaps

into

the

place.

Make

sure

that

it

is

firmly

fixed

in

the

slot

and

does

not

move

easily.

Removing

and

replacing

a

FRU

Lenovo

3000

V100

and

V200

49
