General venting – Lochinvar 80 - 285 User Manual
Page 14
Installation & Operation Manual
14
3
General venting
Figure 3-1 PVC/CPVC Two-Pipe Sidewall
Termination - See page 21 for more details
Figure 3-3
PVC/CPVC Concentric Sidewall
Termination - See page 25 for more details
Direct venting options - Sidewall Vent
Figure 3-2 Stainless Steel Two-Pipe - See page 22
for more details
