WIRE FEEDER ACCESSORIES
bURNbACK TIMER KIT (K419)
Provides a precise control of the electrode burnback
at the end of the weld. Prevents crater sticking and
provides proper stickout for starting the next weld.
Recommended especially when welding with small
(0.023-1/16") diameter wire at high wire feed speeds.
Also includes a cold inch switch. (Can be installed
only in GMA models.) Install the kit according to the M15060 instructions
included with the kit.
ACCESSORIES
C-4 C-4
LN-9 GMA and LN-9F GMA Wire Feeder
GUN AND CAbLE ASSEMbLIES
A variety of standard Lincoln and Magnum gun and
cable assemblies are available for the LN-9 GMA in 10 ft., 12 ft. and 15 ft. cable lengths. Choose the gun
and cable assembly to suit the LN-9 GMA welding
application and wire size. See Table C-1.
TAbLE C.1 – LN-9 GMA GUN AND CAbLE ASSEMbLIES
60% Duty
Process Model Electrode Rating
Gas Metal Arc (GMA) K426 .035-.052” (0.9-1.3 mm) solid 350 amps
.045- 5 ⁄
64
” (1.1-2.0 mm) cored 350 amps
K427 .045- 1 ⁄
16
” (1.1-1.6 mm) solid 500 amps
1 ⁄
16
- 5 ⁄
64
” (1.6-2.0 mm) cored 500 amps
Magnum K470 (1) .035- 1 ⁄
16
” (0.9-1.6 mm) solid 300 amps
.035- 5 ⁄
64
” (0.9-2.0 mm) cored 300 amps
Magnum K471 (1) .035- 1 ⁄
16
” (0.9-1.6 mm) solid 400 amps
.035- 5 ⁄
64
” (0.9-2.0 mm) cored 400 amps
Magnum K478 (2) .035- 1 ⁄
16
” (0.9-1.6 mm) solid 300 amps
.035- 5 ⁄
64
” (0.9-2.0 mm) cored 300 amps
Magnum K479 (2) .035- 1 ⁄
16
” (0.9-1.6 mm) solid 400 amps
0.35- 5 ⁄
64
” (0.9-2.0 mm) cored 400 amps
Innershield ® K126 .068- 5 ⁄
64
” (1.7-2.0 mm) Innershield 350 amps
K115 5 ⁄
64
” (2.0 mm) lnnershield 450 amps
K206 (3) .068- 5 ⁄
64
” (1.7-2.0 mm) Innershield 350 amps
K289 (3) 5 ⁄
64
” (2.0 mm) lnnershield 500 amps
K309 (3) .068- 5 ⁄
64
” (1.7-2.0 mm) lnnershield 250 amps
Submerged Arc K112 1 ⁄
16
” (1.6 mm) Solid 500 amps
(1) K466-1 connector kit required.
(2) K489 Fast-Mate™ Adapter required.
(3) Linconditioner™ guns are recommended for locations where smoke accumulation is a problem and conven-
tional exhaust systems are ineffective. The available smoke removal type Innershield guns and vacuum units
can be used in these locations. Instructions are shipped with the equipment.
