INSTALLATION
A-1
A-1
LN-9 GMA and LN-9F GMA Wire Feeder
TECHNICAL SPECIFICATIONS
INPUT POWER
Supplied by power source: 115 VAC, 50/60 Hz., 350 VA
WIRE FEED SPEED
80 to 980 inches per minute (2.03 to 24.9 meters per minute)
VOLTAGE CONTROL RANGE
12.0 TO 60.0 VDC
TEMPERATURE RANGE
OPERATION:
- 20
o
C to +40
o
C (- 4
o
F to +104
o
F)
Recommended
- 40
o
C to +40
o
C (- 40
o
F to +104
o
F)
Maximum Rated
STORAGE:
- 40
o
C to +85
o
C (- 40
o
F to +185
o
F)
WIRE DIAMETERS
0.023 through 1/16
Solid Electrode
0.045 through 5/64
Cored Electrode
PHYSICAL DIMENSIONS
LENGTH
WIDTH
HEIGHT
TOTAL WEIGHT LESS
ELECTRODE
LN-9 GMA (2 ROLL)
12.15 in.
11.56 in.
12.19 in.
29.3 lbs
(308.4 mm)
(293.4 mm)
(309.4 mm)
(13.3 kg)
LN-9 GMA (4 ROLL)
12.15 in.
11.56 in.
12.19 in.
27.5 lbs
(308.4 mm)
(293.4 mm)
(309.4 mm)
(12.4 kg)
LN-9F GMA Control Box
10.4 in.
6.17 in.
11.26 in.
16.3 lbs
(264 mm)
(156.6 mm)
(293.4 mm)
(7.4 kg)
LN-9F GMA Wire Drive (2 ROLL)
8.06 in.
7.5 in.
12.78 in.
15.6 lbs
(204.6 mm)
(190.4 mm)
(324.4 mm)
(7.1 kg)
LN-9F GMA Wire Drive (4 ROLL)
8.06 in.
7.5 in.
12.78 in.
20.5 lbs
(204.6 mm)
(190.4 mm)
(324.4 mm)
(9.2 kg)
DUTY CYCLE:
The amount of welding performed in a 10 minute period, expressed as a percentage.
