INSTALLATION
A-2
A-2
COMMANDER 300
TECHNICAL SPECIFICATIONS - Commander 300
INPUT - DIESEL ENGINE
Make/Model
Description
Speed (RPM) Displacement
Starting
Capacities
System
Deutz
3 cylinder
1800 Full Load
125 cu. in.
Electric
Fuel: 25 gal.
F3L 1011F
Air/cooled
1900 High Idle
(2.05 liters)
12 VDC
(94.6 liters)
diesel
1400 Low Idle
31 HP
Oil: 6.3 qt.
@ 1800 RPM
(6.0 liters)
RATED OUTPUT - WELDER
Duty Cycle
Welding Output
Volts at Rated Amps
100%
300 amps (DC Multi-purpose)
32 volts
60%
375 amps (DC Multi-purpose)
34 volts
OUTPUT - WELDER AND GENERATOR
Welding Range
Max. Open Circuit Voltage
Auxiliary Power
1
30 - 300 Amps DC
87 OCV
120/240 VAC
in 5 Ranges
@ 1900 RPM
10,000 Watts, 60 Hz.
100% Duty Cycle
PHYSICAL DIMENSIONS
Height
2
Width
Depth
Weight
42.0 in.
31.5 in.
63.1 in.
1325 lbs.
1066.8 mm
800.1 mm
1602.7 mm
1683 lbs.(601 kg)
1
Output rating in watts is equivalent to volt-amperes at unity power factor.
Output voltage is within +/- 10% at all loads up to rated capacity. When welding, available auxiliary power will be reduced.
2
Top of Enclosure. Add 8.9” (16mm) for exhaust.
