5-36 Preliminary January 4, 2001 MAX 6000/3000 Network Configuration Guide
Configuring Frame Relay
Configuring 64 switched Frame Relay connections
6 Exit the profile and, at the exit prompt, select the exit and accept option.
Establishing the connection
To bring up the Frame Relay manually, open the Connection profile and press Ctrl-D, then
select 1=Dial.
If you configure an Answer profile, an incoming call with the correct CLID or DNIS brings up
the session.
Configuring 64 switched Frame Relay connections
You can configure RADIUS to enable the MAX unit to support up to 64 switched Frame Relay
profiles. The unit authenticates and matches callers to switched Frame Relay profiles by
comparing DNIS or CLID information. The MAX unit dials outbound switched Frame Relay
connections on the basis of destination addresses of received packets. Previously, you could
configure Frame Relay profiles only from the VT100 interface.
Examples of RADIUS switched Frame Relay connections
Sample RADIUS Frame Relay Data Link profile
The following sample profile corresponds to both the example in “Sample RADIUS DNIS
profile” on page 5-36 and the example in “Sample RADIUS CLID profile” on page 5-37:
SWITCHED-FR-DTE Password="ascend", User-Service= Dialout-
Framed-User
Ascend-FR-Profile-Name="SWITCHED-FR-DTE",
Ascend-Call-Type=Switched,
Ascend-FR-Type=Ascend-FR-DTE,
Ascend-FR-Link-Mgt=Ascend-FR-T1-617D,
Ascend-FR-N391=6,
Ascend-FR-DTE-N392=3,
Ascend-FR-DTE-N393=4,
Ascend-FR-T391=10
You must set Ascend-Call-Type to Switched. Also, the Frame Relay Data Link
profile’s name must match the value specified in the Ascend-FR-Profile-Name attribute
of the DNIS or CLID profile.
Sample RADIUS DNIS profile
Following is a sample RADIUS DNIS profile:
3762 Password=“Ascend-DNIS”
Ascend-Require-Auth=Not-Require-Auth
User-Service=Framed-User,
Framed-Protocol=FR,
Framed-Address=10.10.10.212,
Framed-Netmask=255.255.255.0,
Ascend-Route-IP=Route-IP-Yes,
