Contents
MAX 6000/3000 Network Configuration Guide xvii
Macintosh software................................................................................................ 9-36
TCP/IP software configuration .............................................................................. 9-36
Examples of WAN interface configuration .................................................................. 9-36
Configuring dynamic address assignment to a dial-in host ................................... 9-36
Configuring a host connection with a static address ............................................. 9-38
Configuring an IP Direct connection..................................................................... 9-40
Configuring a router-to-router connection ............................................................ 9-41
Configuring a router-to-router connection on a subnet ......................................... 9-42
Configuring a numbered interface ......................................................................... 9-44
Type of service (TOS) support for selecting quality of service.................................... 9-46
Defining TOS policy within a profile.................................................................... 9-46
Defining TOS filters .............................................................................................. 9-49
Examples of connection-based TOS configuration ............................................... 9-49
Example of defining a TOS filter .......................................................................... 9-53
Example of applying TOS filters to WAN connections ........................................ 9-54
Configuring IP routes........................................................................................................... 9-55
Static routes................................................................................................................... 9-55
Dynamic routes ............................................................................................................. 9-56
Route preferences and metrics on a MAX unit............................................................. 9-56
Static route configuration.............................................................................................. 9-56
Settings in a Static Route profile ........................................................................... 9-56
Settings in a RADIUS route profiles ..................................................................... 9-58
Route settings in a RADIUS user profile .............................................................. 9-58
Connection-specific private static routes (RADIUS only) .................................... 9-59
Configuring the default route ................................................................................ 9-59
Defining a static route to a remote subnet ............................................................. 9-60
Example of route preferences configuration.......................................................... 9-60
Dynamic route configuration ........................................................................................ 9-61
Example of RIP and ICMP configuration..................................................................... 9-62
Chapter 10 Setting Up IP Multicast Forwarding ............................................ 10-1
Introduction to multicast forwarding ................................................................................... 10-1
Configuring multicast forwarding........................................................................................ 10-2
Enabling multicast forwarding...................................................................................... 10-2
Identifying the MBONE interface ................................................................................ 10-2
Multicast forwarder polling activities........................................................................... 10-2
Configuring the MAX to support multicast clients ...................................................... 10-2
Specifying the interfaces that support multicast clients ........................................ 10-2
Specifying the rate which multicast clients accept packets ................................... 10-3
Querying for active group members ...................................................................... 10-3
Multicast interfaces....................................................................................................... 10-3
Implicit priority setting for dropping multicast packets ............................................... 10-4
Monitoring connectivity problems through heartbeat monitoring................................ 10-4
Examples of multicast forwarding configuration................................................................. 10-5
Forwarding from an MBONE router on Ethernet......................................................... 10-5
Forwarding from an MBONE router on a WAN link................................................... 10-6
Configuring the MAX to respond to multicast clients .......................................... 10-7
Configuring the MBONE interface ....................................................................... 10-7
Configuring multicasting on WAN interfaces....................................................... 10-7
