8. Attach the 4-P IN (4P) and 16-P IN (16P) C ONNECTORS to the
corresponding J ACKS on the back of the C ONSOLE A SSEMBLY (4).
9. Feed any excess W IRE H ARNESS (E) down into the C ONSOLE
S
UPPORT
A
SSEMBLY
(7). Secure the C
ONSOLE
A
SSEMBLY
(4) to the
C ONSOLE S UPPORT A SSEMBLY using four P HILLIPS P AN H EAD
S CREWS (2). Tighten the S CREWS securely.
CAUTION: Do not over-tighten the P HILLIPS P AN H EAD
S
CREWS
(2).
CAUTION: Be careful not to pinch the W
IRE
H
ARNESS
(E) when
assembling the C ONSOLE A SSEMBLY (4) to the C ONSOLE S UPPORT
A SSEMBLY (7).
10. Locate and install the C ONSOLE S UPPORT C AP (19) onto the
C
ONSOLE
S
UPPORT
A
SSEMBLY
(7) as shown using four C
AP
S
CREWS
(21).
11. Place the B ACK M ONOCOLUMN C OVER (6) over the P IVOT S HAFT (H)
at the top of the M ONOCOLUMN (F).
12. Place the F RONT M ONOCOLUMN C OVER (5) on the opposite side of
the B
ACK
M
ONOCOLUMN
C
OVER
(6) to cover the P
IVOT
S
HAFT
(G)
and C ONSOLE S UPPORT A SSEMBLY M OUNTING S CREWS . Interlock the
top tabs and use two P HILLIPS P AN H EAD P OINTED S CREWS (3) to
secure the bottoms of the M
ONOCOLUMN
C
OVERS
together.
Tighten the S
CREWS
securely.
CAUTION: Do not over-tighten the P
HILLIPS
P
AN
H
EAD
P
OINTED
S CREWS (3).
13. Locate one F RONT R OCKER C OVER (13) and one B ACK R OCKER
C
OVER
(14). Position the F
RONT
R
OCKER
C
OVER
over the user
side of the left end of the P
IVOT
S
HAFT
(H) (as shown) making
sure that it interlocks with the M ONOCOLUMN C OVERS (5 & 6).
Place the B
ACK
R
OCKER
C
OVER
over the opposite side of the left
end of the P
IVOT
S
HAFT
in the same manner. Secure the C
OVERS
using three P HILLIPS P AN H EAD P OINTED S CREWS (3). Repeat the
procedure reversing front and back for the user right end of the
P
IVOT
S
HAFT
.
CAUTION: Do not over-tighten the P
HILLIPS
P
AN
H
EAD
P
OINTED
S CREWS (3).
