COMPONENT LIST
# Part Description Qty. # Part Description Qty.
1
Hex Socket Head Cap Screw
3/8-16 X 1”
0017-00101-1645
8 2
Phillips Pan Head Screw
#8-18 X 3/4”
0017-00101-1744
4
3
Phillips Pan Head Pointed Screw
#8-18 X 3/4”
0017- 00101-1242
18 4
Console Assembly
(shipped separately)
1
5 Front Monocolumn Cover 1 6 Back Monocolumn Cover 1
7 Console Support Assembly 1 8
Flat Washer
0017-00104-0192
2
9 Left Front Cover 1 10 Right Front Cover 1
11 Left User Arm Assembly 1 12 Right User Arm Assembly 1
13 Front Rocker Cover 2 14 Back Rocker Cover 2
17 Accessory Tray 1 18
Internal Tooth Lock Washer
0017-00104-0450
6
19 Cap: Console Support 1 20
Grommet
0017-00042-0754
4
21
Cap Screw T-27
0017-00101-1746
4 22 Cup 1
23 Pad 1
Tools Required for Assembly
l
Magnetic #2 Bit Phillips Screwdriver
l
5/16” Hex Key Wrench
l
T-27 Torx Key Wrench
3
