7 Chapter 3: Getting to Know the Wireless-G Access Point with SRX
The Back Panel
Wireless-G Access Point with SRX
The Back Panel
The Access Point's Ethernet network and power ports, as well as the Reset button, are located on the back panel.
Reset Button There are two ways to reset the Access Point's factory defaults. Either press the Reset button,
for approximately ten seconds, or use the Administration - Factory Defaults screen of the
Access Point's Web-based Utility.
Ethernet Port The Ethernet network port connects to an Ethernet network device, such as a switch or router.
Power Port The Power port connects to the Access Point’s power adapter.
Figure 3-2: Back Panel
port: the connection point on a computer or
networking device used for plugging in
cables or adapters
IMPORTANT: Resetting the Access Point will erase
all of your settings (including wireless security, IP
address, and power output) and replace them with
the factory defaults. Do not reset the Access Point
if you want to retain these settings.
