Section 5: Specifications & Capacities
AT2672 Grooming Mowers 310-302M
Land Pride
07/02/07
Table of Contents
Section 5: Specifications & Capacities
AT26 Air Tunnel Series
AT2672
Maximum Engine Horsepower 50 HP
Cutting Width 72”
Overall Width 91 1/2”
Height 39”
Length 63”
Weight 672 lbs.
Mowing Height 3/4” - 5 1/4” (1/2” increments)
Deck Material Thickness 3/16”
Blades 3 Blades Offset Design
1/4” x 2 1/2” x 25”
Heat Treated Alloy Steel
Blade Overlap 1 1/2”
Blade Tip Speed 18,134 FPM
Hitch Category l Floating Top Link
Adjustable Clevises
Gauge Wheels - 4 each Castered 3 1/4” x 10” Solid rubber tires
Wheel Spindle 1” Diameter with Greasable Bushing
540 RPM PTO Gearbox
Drive Train 1:2.5 Ratio, Cast Iron Housing
B-Section V-Belt
Grass Chute Hinged-Adjustable
Front Roller Optional
Gearbox 540 RPM, Cast Iron Housing, Beveled Gears
Driveline Heavy-Duty with Quick Coupler
