Specifi cations
Current consumption at 24V (without detectors/modules) typ. 25mA
Idle loop current typ. 300µA per detector/module
Total loop current max. 300mA (at reduced line resistance)
Idle loop voltage typ. 26V (Apollo/Discovery) or
typ. 29V (System Sensor/200), respectively
Loop line resistance max. 50Ω per core
Ambient temperature -5°C to +50°C
Dimensions L × W × H 132 Ч 74 Ч 10 (mm)
Weight 80g
Part No. 214021
Order name Loop Interface LIF64-1
