A-2 INSTALLATION A-2
INVERTEC STT II (CE)
STANDARD VOLTAGE INPUT CURRENT AT RATED OUTPUT
200/208/380/400/415/3/50/60 HZ 36/34/20/19/18
TECHNICAL SPECIFICATIONS –INVERTEC STT II (CE) (For Code 11367)
INPUT- THREE PHASE ONLY
RATED OUTPUT
RECOMMENDED INPUT WIRE AND FUSE SIZES
I NPUT VOLTAGE FUSE(SUPER LAG) INPUT AMPERE TYPE 75°C TYPE 75°C
AND FREQUENCY OR BREAKER RATING ON COPPER COPPER
SIZE NAMEPLATE SUPPLY WIRE GROUND WIRE
IN CONDUIT IN CONDUIT
AWG (IEC) SIZES AWG (IEC) SIZES
200/50/60 40 36
208/50/60 40 34
380/50/60 30 20 10 (6 mm2) 10 (6 mm2)
400/50/60 30 19
415/50/60 30 18
HEIGHT WIDTH DEPTH WEIGHT
23.2 in 13.2 in. 24.4 in. 100 lbs.
589 mm 336 mm 620 mm 46 kg
OUTPUT
DUTY CYCLE AMPS VOLTS AT RATED AMPS
60% Duty Cycle 225 29
100% Duty Cycle 200 28
CURRENT RANGE OPEN CIRCUIT VOLTAGE AUXILIARY POWER
Peak Current 0 - 450 Amps 88 VDC Maximum 115 1 VAC @ 4 Amps
Background 0 - 125 Amps 42 VAC @ 4 Amps
1 115 VAC not present on European Models.
PHYSICAL DIMENSIONS
