Specifications
SPECIFICATIONS
Microphone Input: Female XLR Pin 2 Hot
Input Impedance: 600 Ohms balanced
GAIN: +50 dB
EIN: −115 dB A-weighted @ +50dB gain (150 Ohm source impedance)
Maximum Input Level: –7 dBu
Frequency Response: +0, −0.5 dB 20 Hz - 20 kHz, ref. 1 kHz
THD+N: <.005%, 20 Hz - 20 kHz
Line Inputs: (2) 1/4" TRS balanced or unbalanced
Input Impedance: 20 kOhm balanced, 10 kOhm unbalanced
Maximum Input Level: +13 dBu
Frequency Response: +0, −0.5 dB 20 Hz - 20 kHz, ref. 1kHz
THD+N: <.009% A/D, 20 Hz - 20 kHz
Instrument Input: (1) 1/4" mono jack
Input Impedance: 1 MOhm unbalanced
Maximum Input Level: +8.5 dBu
Frequency Response: +0, −1 dB 20 Hz - 20 kHz, ref. 1 kHz
THD+N: <.0125% A/D
Line Outputs: (2) 1/4" TRS balanced or unbalanced
Level: +16 dBu maximum
Impedance: 1 KOhm Balanced, 500 Ohm Unbalanced
Headphone Output: (1) 1/8" stereo jack 20 mW per channel at 50 Ohms
Sample Rate:
44.1 kHz or 48 kHz (determined by computer application)
Dynamic Range: A/D (24 Bit) 100 dB typical, A-weighted, 20 Hz - 20 kHz
D/A (24 Bit) 100 dB typical, A-weighted, 20 Hz - 20 kHz
A/D/A (24 Bit) 97 dB typical, A-weighted, 20 Hz - 20 kHz
Power Requirements: USB powered
Dimensions: 6.7 x 6.5 x 1.5
Weight: 1.13 lbs.
Lexicon engineers are constantly working to improve the quality of our products.Specifications are therefore
subject to change without notice.
