MTFP FRONT PULLDOWN
SEAT FRAME ASSEMBLY
ITEM NO. QTY. PART NO. DESCRIPTION
1 1 MTDP-S0002 Seat Frame Weldment
2 1 7359401 Seatrack, Roller Serrated
3 1 7359501 Seatrack, Roller Flat
4 1 AK50-A1007 MTS SEAT#2 ASSM. (ROLLER)
5 2 0017-00101-1662 M10 X 64 HXS SOC CS ST ZN
6 4 0017-00104-0377 3/8" Internal Lock Washer
7 2 0017-00103-0289 10mm THIN NYLOC NUT
8 1 73763 ROLLER ASSM.
9 2 0017-00103-0217 3/8" Thin Lock Nut
10 1 0017-00101-1408 3/8 X 2 3/4 Bolt
11 1 0017-00101-1664 3/8" FLAT HEAD BOLT
12 1 M051-00296-A000 NUMBER STRIP (1-12)
13 1 0017-00042-0945 1 1/2 X 2 Endcap
14 1 M051-00602-A000 MTAB SEAT INSTR. DECAL
15 1 7442601 MTS SEAT EXTENSION SPRING
