F-12 DIAGRAMS F-12
COMMANDER 500
CONNECTION DIAGRAM:
TO WORK
K963-1 HAND AMPTROL
-OR-
K814 ARC START SWITCH
K870 FOOT AMPTROL
-OR-
14 PIN AMPHENOL
S24062 7-18-98
N.B. ATTACH ELECTRODE AND WORK LEADS OF TIG MODULE TO THE POSITIVE AND NEGATIVE STUDS OF WELDER TO SELECT DESIRED ELECTRODE P
OLARITY.
Keep guards in place. Keep away from moving parts.
WARNING
Only qualified personnel should install,use or service this equipment.
Do not operate with panels open. Disconnect NEGATIVE (-) BATTERY LEAD
COMMANDER / K930 TIG MODULE / CONNECTION DIAGRAM
CAUTION : AN INCREASE IN THE THE AC AUXILIARY VOLTAGE. IF THIS VOLTAGE GOES OVER 140 VOLTS, WIRE FEEDER CONTROL CIRCUITS MAY BE ANY INCREASE OF THE HIGH IDLE ENGINE RPM BY CHANGING THE GOVERNOR SETTING OR OVERRIDING THE THROTTLE LINKAGE WILL CAUSE
N.E. PLACE IDLER SWITCH IN "AUTO" OR "HIGH" IDLE AS DESIRED.
THE ENGINE WELDER OPERATING MANUAL.
N.C. PLACE WELDER TERMINALS SWITCH TO " REMOTELY CONTROLLED" POSITION. N.D. PLACE OUTPUT CONTROL SWITCH IN "REMOTE CONTROL" POSITION. N.A. WELDING CABLES MUST BE OF PROPER CAPACITY FOR THE CURRENT AND DUTY CYCLE OF IMMEDIATE AND FUTURE
APPLICATIONS. SEE OPERATING MANUAL.
DAMAGED. THE ENGINE GOVERNOR SETTING IS PRE-SET AT THE FACTORY - DO NOT ADJUST ABOVE RPM SPECIFICATIONS LISTED IN FLOWMETER
before servicing. Do not touch electrically live parts.
REGULATOR
TO GAS
INPUT FITTING
ARGON GAS
K936-1 CONTROL CABLE
CYLINDER
ELECTRODE
