©-11/08-Printed in U.S.A. 4 of 4 SWH-RP Rev B
ITEM
NO.
PART NO. DESCRIPTION MODEL NO.
GAS VALVES (Continued)
15 MSC30005 AIR INLET KIT SNR150
15 MSC30006 AIR INLET KIT SNR200
15 MSC30007 AIR INLET KIT SNA285
15 MSC30008 AIR INLET KIT SNA400
15 MSC30009 AIR INLET KIT SNA500
PILOT & BURNER ASSEMBLIES
16 PLT3022 FLAME SENSOR WITH GASKET ALL
17 GKT2450 FLAME SENSOR GASKET ALL
18 PLT3021 IGNITOR WITH GASKET ALL
19 GKT2449 IGNITOR GASKET ALL
20 BNR3426 BURNER W/ GASKET SNR150
20 BNR3427 BURNER W/ GASKET SNR200
20 BNR3428 BURNER W/ GASKET SNA285
20 BNR3429 BURNER W/ GASKET SNA400-500
21 GKT2451 BURNER GASKET ALL
22 WTR3082 GAS/AIR ARM ASSEMBLY W/ GASKET SNR150
22 WTR3078 GAS/AIR ARM ASSEMBLY W/ GASKET SNR200, SNA285-400
22 WTR3079 GAS/AIR ARM ASSEMBLY W/ GASKET SNA500
23 WTR3080 HEAT EXCHANGER ACCESS DOOR KIT ALL
MISCELLANEOUS
24 MSC3180 SIGHT GLASS WITH GASKET ALL
25 GKT2453 SIGHT GLASS GASKET ALL
26 FIB2168 INSULATION, BURNER PLATE DOOR ALL
27 FIB2167 INSULATION BAFFLE, DIVIDER PLATE ALL
28 MSC20007 DISPLAY BEZEL LOWER ALL
29 MSC20023 DISPLAY BEZEL UPPER SNR150-200
29 MSC20037 DISPLAY BEZEL UPPER SNA285-500
30 RLV2006 T & P RELIEF 3/4 X 150M SNR150-200 & SNA258-400
30 RLV2017 T & P RELIEF 3/4 X 150M SNA500
31 MSC20036 CONDENSATE TRAP ALL
32 SWT2011 BLOCKED DRAIN SWITCH ALL
33 TST3403 FLUE TEMP SENSOR KIT ALL
34 GKT2455 GASKET DOOR RUBBER ALL
35 GKT2452 GASKET DOOR ROPE ALL
- TST2044 1/4" BULBWELL ALL
- TST2032 TANK SENSOR ALL
- FUS2000 1.25 AMP ALL
- FUS2001 3.15 AMP ALL
- FUS2002 5 AMP ALL
- KIT30049 MRLWCO WITH TEST ALL
- KIT3087 NEUTRALIZER KIT ALL
- WTR2500 ANODE ROD, MAGNESIUM ALL
PUMPS
36 PUM3010 PUMP W/ FLANGES AND HARDWARE SNR150-200
36 PUM3011 PUMP W/ FLANGES AND HARDWARE SNA285
36 PUM3012 PUMP W/ FLANGES AND HARDWARE SNA400-500
37 ARM1078 PUMP FLANGE SNR150-200
37 ARM1079 PUMP FLANGE SNA285
37 ARM1080 PUMP FLANGE SNA400-500
- ARM1015 PUMP FLANGE GASKET SNR150-200, SNA285
- ARM1081 PUMP FLANGE GASKET SNA400-500
PLEASE HAVE SERIAL NUMBER AVAILABLE WHEN ORDERING PARTS.
