Linksys BEPSR11 - Manual (Page 23)

EtherFast ® Cable/DSL Routers
4. Select Internet Protocol (TCP/IP), as shown in Figure 7-4, and click the
Properties button.
5. Select Obtain an IP address automatically, as shown in Figure 7-5. Once
the new window appears, click the OK button. Click the OK button again
to complete the PC configuration.
6. Restart your computer.
Go to “Chapter 8: Configure the Router.”
39
Instant Broadband ™ Series
1. Go to the Network screen by clicking the Start button. Click Settings and
then Control Panel. From there, double-click the Network and Dial-up
Connections icon.
2. Select the Local Area Connection icon for the applicable Ethernet adapter
(usually it is the first Local Area Connection listed). Do not choose a
TCP/IP entry whose name mentions DUN, PPPoE, VPN, or AOL. Double-
click the Local Area Connection.
3. The Local Area Connection Status screen will appear, as shown in Figure 7-
3. Click the Properties button.
38
Figure 7-4
Figure 7-5
Configuring Windows 2000 PCs
Figure 7-3
