To restore your temporary IP address configuration, follow the steps below:
1. Follow steps 1 and 2 in the instructions above.
2. Select either Specify an IP address or Obtain IP address automatically
and enter in the original values you noted earlier.
3. Click OK and click OK again in the Network window.
4. Restart your computer.
If you wish to run the SNMP
Configuration Utility, click on
Start,
Programs, WAP11
Configuration Utility, and
WAP11 SNMP.
When you first start the Access
Point SNMP Configuration Utility,
a screen will appear asking you to
enter the Wireless Network Access
Point’s IP Address.
Enter the IP Address—192.168.1.250 is the default setting—and Password—pub-
lic is the default password—and then click the OK button to continue.
(As this is a private IP address, you do not need to purchase an additional IP
Address from your service provider.)
29
The Access Point’s SNMP
Configuration Utility
The Access Point SNMP Configuration Utility is provided to allow you further
customization of the Wireless Network Access Point and your wireless network
through your Ethernet or wireless connection. It is strongly recommended that you
use your wireless connection to use the SNMP Configuration Utility.
If you wish to use the SNMP Configuration Utility to configure the Access
Point, you must assign a temporary IP address to your computer.
You may need to assign the PC a temporary IP address to gain access to the
Access Point.
1. This can be done at Start, Settings, Control Panel, then Network.
2. Click on the network adapter associated with the TCP/IP and click
Properties.
3. Note your current settings in order to restore your TCP/IP configuration.
4. Select Specify an IP address and enter the following values:
IP - 192.168.1.50, Subnet Mask- 255.255.255.0
5. Click OK and click OK again in the Network window.
6. Restart the computer when asked.
Make sure that you enter an IP address for the Access Point in order to access
it at a later time. Once you have completed the IP Address Configuration, you
can set the PC back to its previous settings. For example, to “Obtain an IP
Address automatically.”
28
Configuring the Wireless Network Access Point
with the Access Point’s SNMP Configuration Utility
Wireless Network Access Point
Creating a Temporary IP Address
Instant Wireless TM Series
DEFAULT SETTINGS:
The default IP Address is: 192.168.1.250
The default SubNet Mask is: 255.255.255.0
Linux/Unix Users: Though these operating systems are not supported by
Linksys, the Wireless Access Point should work in these environments. The
WAP11 can be configured under these operating systems using SNMP. A
configurable Management Information Base file (MIB) named
AT76C510.MIB can be found on the Setup Utility CD. This file is for
Linux/Unix users only, and is not necessary for any Windows installation.
