9
Chapter 3: Connecting the Cable
Gateway
You will connect the Cable Gateway to your Cable service’s coaxial cable line
and to the computers in your home or business. With the Cable Gateway, you
can use a standard Ethernet connection or connect via USB. For Ethernet con-
nection continue with the Ethernet Cable Connection section. For USB con-
nection, go to the next section, USB Cable Connection.
First, make sure that all the devices that you’ll be working with are powered
down, including your PCs and the Cable Gateway.
1. Connect the coaxial
cable that is provided
by your cable service
provider to the Cable
port that is on the
back of the Cable
Gateway, as shown in
Figure 3-1.
2. Connect one end of an Ethernet cable to your PC’s Ethernet adapter, as shown
in Figure 3-2.
Note: If your PC’s Ethernet adapter is not set up, please refer to the Ethernet
adapter’s user guide for more information.
Figure 3-1
Figure 3-2
The USB icon, shown in Figure 2-3, marks a USB port on a PC or device.
The Cable Gateway comes with one USB cable. Connect one end of the USB
cable to the Cable Gateway. Connect the other end to a computer’s USB port.
The picture shows two USB ports as they might appear on
your computer. Note the two USB icons marking the
ports.
8
The USB Icon
Figure 2-3
USB Cabling
Figure 5-2
Wireless-G Cable Gateway
Overview
Ethernet Port Connection
