UDP
UDS-10 User Guide 8-7
8.3 Setup Records
A setup record consists of 120 bytes. They are transmitted at once from and to the node.
Unused bytes should be initialized as 00. Table 21 - Setup Record Construction defines the
structure of a setup record:
Table 21 - Setup Record Construction
Byte(s) Function
00-03 IP address of the unit (x.x.x.x)
04 Reserved (0)
05 Flag BYTE
Bit 7: Reserved (0)
Bit 6: Set 1 for AUI, 0 for 10BASE-T (CoBox-Micro only)
Bits 5-0: Reserved (0)
06 Number of host bits for subnetting; if 0, matching standard netmask for Class A,
B, C is used.
07 Reserved (0)
08-11 Telnet configuration password (0 if not used)
12-15 Gateway IP address (0,0,0,0 if not used)
16-63 48-byte Channel 1 parameters; parameter setup Channel 1 (see Table E-4:
Channel Parameters)
64-111 48-byte Channel 2 parameters; parameter setup Channel 2 (see Table E-4:
Channel Parameters))
112-119 Reserved (0)
