Liebert RCM8DO - Manual (Page 43)

Local String with Master Repeater, and Optional Pager Dial-out
B-3
Master #1 Optional Slave #4 Optional Slave #3 Slave #2
Inputs 25-32 Inputs 17-24 Inputs 1-8
Master Repeater
Inputs 9-16
“24-Hour Attended
Security Station”
“Main Computer Room”
