B-1
Appendix B: Typical Configurations
The RCM8 can be configured with tremendous
flexibility, in order to accommodate various
applications. The following diagrams illustrate some
typical system configurations.
Refer to Chapter 2 for complete explanation of DIP
Switch settings.
Standalone Operation with Optional Pager Dial-out and Optional SiteScan Connection
Master #1 Typical
DIP Switch Setting
Numeric
or Alphanumeric Pager
External Modem
Alarm Inputs 1-8
SiteScan
SiteLink Module
