ACCESSORY COMPONENTS CONTINUED
Tall Arch Pane Door
Style View Doors Continued -
Style View Doors also come in a Tall Arch Pane Design. Two distinctive grille kits, the “Crescents” and “Sunrise” design, are
also offered separately. They are easy to install and will not require hardware to attach them to the standard glass door frame.
The door includes heavy duty magnet door latches and functional twin-pane doors. Style View Doors and Grille Kits are not
available for EBVPF models.
“Crescents” Grille Kits “Sunrise” Grille Kits
TALL ARCH PANE DOORS
Cat. No. Model Description Model Series
40” Arch Pane Doors, Black
EBST
40” Arch Pane Doors, Satin Pewter
H3529 TAPD40C
H3531 TAPD40SP
“Crescents” Grille Kits
Cat. No. Model Description Model Series
H3549 CUGK40C 40” Crescents Upper Grille Kit, Black
EBST
H3551 40” Crescents Upper Grille Kit, Satin Pewter CUGK40SP
H3553 CLGK40C 40” Crescents Lower Grille Kit, Black
H3555 40” Crescents Lower Grille Kit, Satin Pewter CLGK40SP
“Sunrise” Grille Kits
Cat. No. Model Description Model Series
H3573 SUGK40C 40” Sunrise Upper Grille Kit, Black
EBST
H3575 40” Sunrise Upper Grille Kit, Satin Pewter SUGK40SP
H3577 SLGK40C 40” Sunrise Lower Grille Kit, Black
H3579 40” Sunrise Lower Grille Kit, Satin Pewter SLGK40SP
Style View™ Doors
Style View™ doors come in three styles. They are easy to install onto the standard glass door frame. Includes heavy-duty magnetic
door latches and functional twin-pane doors. Style View Doors and Grille Kits are not available for the EBVPF model fireplaces.
Arch Design Arch Pane Design Square Pane Design
ARCH DESIGN KITS
Cat. No. Model Description Model Series
H8771 AD40B-2 40” Arch Doors, Black
EBVST
H8772 AD40SP-2 40” Arch Doors, Satin Pewter
ARCH PANE DESIGN KITS
H8777 APD40C-2 40” Arch Pane Doors, Black
EBVST
H8778 APD40SP-2 40” Arch Pane Doors, Satin Pewter
SQUARE PANE DESIGN KITS
H8783 SPD40C-2 40” Sq. Pane Doors, Black
EBVST
H8784 SPD40SP-2 40” Sq. Pane Doors, Satin Pewter
“Sunrise” Grille Kits
H3573 SUGK40C 40” Sunrise Upper Grille Kit, Black
EBVST
H3575 SUGK40SP 40” Sunrise Upper Grille Kit, Satin Pewter
H3577 SLGK40C 40” Sunrise Lower Grille Kit, Black
H3579 SLGK40SP 40” Sunrise Lower Grille Kit, Satin Pewter
