NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
11
WIRINg DIAgRAM - 240 VOLT
Wiring diagrams are provided here for reference purposes only. This information is also provided on schematics attached directly to the appliance
on the left side.
CAUTION: LAbEL ALL WIRES PRIOR TO DISCONNECTION WHEN SERVICINg CONTROLS. WIRINg ERRORS CAN CAUSE IMPROPER AND DAN-
gEROUS APPLIANCE OPERATION.
WIRINg - 240 VOLT
Figure 21
Figure 22
HOME POWER SUPPLy
240 VAC
120 V (L1) + 120 V (L2) = 240 V
FIREPLACE WIRE
HARNESS
Control Panel
Flame / Ember
On/Off Switch
Control Panel
Heater On/Off
Switch
.
Wall Thermostat
Wall Switch
(power on/off)
Outside Switches
Control Panel
(power on/off)
Transformer
Temperature Sensor
Remote Sensor
PTC
Heater 1 (L)
Heater 2 (L)
Fan Motor (L)
Flame Motor (L)
Light (L)
L-R1
L-R2
L-FAN
L-M
P-L
L-LIGHT
L1
L2
N1
N2
N
MAIN POWER
L1
L2
N
N-FLAM
E
L-FLAM
E
SIP4
K-P
SIP2
REMOTE
SIP3
K-H
TEM
.
SIP6 N-LIGH
T
POWER-N N-F
AN N-M
P-TRA.
SIP11
SIP7
T-P
LIGHT
SIP13
Circuit
Board
GROUND
T105° C
HOME POWER
SUPPLy
240 VAC
120 VAC
120 VAC
WHITE
bLACK
ORANgE
bLUE
bLUE
yELLOW AND gREEN
gROUND
N
L1
L2
240 V 3000 W
gROUND
N
L1
L2
N1
N2
See Power Supply Specifications on Page 3.
WARNINg
Do not install or operate this fireplace through a switch wired in the 120 VAC or 240 VAC circuits. The only approved
wiring for a switch is through the low voltage circuit (24 VAC) as shown on Page 14.
L1 = BLACK (POWER)
L2 = ORANGE (POWER)
G = GREEN (GROUND)
N = WHITE (COMMON)
N1 = BLUE (COMMON)
N2 = BLUE (COMMON)
THE 120 VOLT POWER CORD INSTALLED ON
THIS APPLIANCE MUST bE REMOVED (SEE
INSTRUCTION #2 ON PAgE 5).
