PREP

AR
A

ION

Desktop Pedestal Installation

For proper ventilation, allow a clearance of 4" on each side and from the wall.

GROUNDING

Ensure that you connect the earth ground wire to prevent
possible electric shock. If grounding methods are not pos-
sible, have a qualified electrician install a separate circuit
breaker. Do not try to ground the unit by connecting it to
telephone wires, lightening rods, or gas pipes.

Power Supply

Short-circuit

Breaker

■

The set can be installed in various ways such as on a wall, or on a desktop etc.

■

The set is designed to be mounted horizontally.

4 inches

When not using the desk-type stand (60PC4* only)

When not using the desk-type stand,
install the supplied rubber caps for
protecting the desk-type stand fixture
as shown at the figure.

Rubber cap
