Parts List
21
REF# KEYS PART#
DESCRIPTION
QTY. REF# KEYS PART#
DESCRIPTION
QTY.
A1
323-00158
A7r Main Frame Assy
1
F2
302-00278
A7r & A7u Spring Washer SW5
3
A3
331-00038
A7r & A7u Bearing
2
F3
302-00231
A7r & A7u Flat Washer M5 (5.3*10*1)
3
X1
324-00001
A7r & A7u Bottom Bracket Set
1
F4
319-00005
A7r & A7u Axle Assembly Idler
1
A9
311-00043
A7r & A7u Crank Pulley
1
F5
302-00309
A7r C Ring 8
1
A10
302-00273
A7r & A7u Sensor Magnetic
1
X3
324-00003
A7r & A7u Aluminum Idler Wheel Assembly
1
A11
304-00016
A7r Poly-v Belt J6 762L
1
F8
331-00045
A7r & A7u DU Bearing
3
A12
330-00045
A7r & A7u Crank
1
F9
330-00053
A7r Idler Arm Assembly
1
A13
306-00311
A7r & A7u Pedal L & R
1
F10
302-00223
A7r & A7u C Ring 14
1
A14
330-00046
A7r & A7u Crank and Pulley Axle
1
F11
302-00275
A7r & A7u Spring
1
A15
331-00039
A7r & A7u Bearing
3
G1
311-00044
A7r & A7u Generator
1
A16
302-00218
A7r & A7u C Ring 25
1
G2
302-00220
A7r & A7u C Ring 15
2
X2
324-00002
A7r & A7u Poly of Second Axle Assembly
1
G3
331-00040
A7r & A7u Bearing (6002LLU)
1
A21
302-00219
A7r & A7u C Ring 17
1
G4
319-00007
A7r & A7u Generator Base
1
A22
304-00014
A7r Poly-v Belt
1
G5
306-00314
A7r & A7u Shielding Pad
1
A23
302-00263
A7r & A7u Round Head Screw M5*0.8*10
4
G6
302-00228
A7r & A7u Flat Washer M5 (5.5*13*1)
4
A24
302-00228
A7r & A7u Flat Washer M5 (5.5*13*1)
4
G7
302-00259
A7r & A7u Round Head Allen Bolt M5*0.8*30
4
A25
302-00242
A7r & A7u Hex Nut M4*0.7
4
G8
302-00217
A7r & A7u Bushing 25*22
5
A26
302-00264
A7r & A7u Round Head Screw M4*0.7*10
4
G9
302-00233
A7r & A7u Flat Washer M8 (8.5*26*2.5)
5
A27
313-00102
A7r Wire of Load Resister A
2
G10
302-00277
A7r & A7u Spring Washer SW8
4
A28
313-00103
A7r Wire of Load Resister B
1
G11
302-00260
A7r & A7u Round Head Allen Bolt M8*1.25*45
4
A29
307-00061
A7r & A7u Load Resister
2
G12
302-00279
A7r Round Head Allen Bolt M8*1.25*55
1
A30
302-00243
A7r Hex Nut M6*1.0
2
H1
323-00164
A7r Console Tube
1
A31
302-00265
A7r & A7u Round Head Screw M3*0.5*8
2
H2
310-00124
A7r Grip for Front Handlebar
1
A32
313-00089
A7r Sensor Cable
1
H3
306-00307
A7r & A7u Handlebar End Cap
2
A33
302-00308
A7r & A7u Sensor Cable Bracket
1
H4
310-00123
A7r & A7u Water bottle Holder
1
A34
313-00080
A7r Lower Wire Harness
1
H5
302-00268
A7r & A7u Round Head Screw M5*0.8*15
2
A35
313-00101
A7r Output Generator Wire
1
H6
307-00059
A7r & A7u Console
1
A36
307-00060
A7r & A7u Control Board Ver3.1
1
H7
302-00228
A7r & A7u Flat Washer M5 (5.5*13*1)
6
B1
305-00052
A7r Shroud-Right
1
H8
302-00225
A7r & A7u Flat Head Allen Bolt M8*1.25*16
4
B2
305-00051
A7r Shroud-Left
1
H9
313-00084
A7r Upper Wire Hardness #24AGW#800mm
1
B3
302-00266
A7r & A7u Round Head Screw M5*0.8*15
14
H10
313-00083
A7r Upper Heart Rate Sensor wire
1
B4
306-00304
A7r & A7u Decoration Cap
2
H11
306-00315
A7r Console Tube Cover
1
B5
306-00309
A7r Hit Shielding Right
1
H12
319-00009
A7r Reading Rack
1
B6
306-00359
A7r Hit Shielding Left
1
J1
323-00157
A7r Aluminum Rail
1
B7
302-00267
A7r Round Head Screw M5*0.8*20
1
J2
302-00226
A7r Flat Head Allen Bolt M6*1.0*16
8
C1
323-00159
A7r & A7u Front Stabilizer Assembly
1
J3
302-00269
A7r Round Head Screw M6*1*105
2
C2
310-00122
A7r & A7u Adjusting Knob
4
J4
302-00235
A7r Flat Washer M6 (6.5*13*1)
4
C3
306-00306
A7r & A7u Foot Cap
4
J5
306-00316
A7r Stopper 15*6*20
4
C4
306-00310
A7r & A7u Leveling Base
4
J6
302-00254
A7r & A7u Nylon Nut M6*1
2
C5
302-00244
A7r & A7u Hex Nut M6*1*40
2
J7
306-00317
A7r Stopper 13.5*17*13
2
C6
302-00229
A7r & A7u Flat Washer M6 (6.5*13*1)
4
J8
302-00236
A7r Flat Washer M6 (6.2*19*2)
2
C7
302-00254
A7r & A7u Nylon Nut M6*1
2
J9
302-00247
A7r Hex Screw M6*1*10
2
C8
306-00318
A7r & A7u Transportation Wheel 3*23
2
J10
306-00302
A7r Aluminum Rail Front Cover
1
C9
302-00230
A7r & A7u Flat Washer 8.4*17*2
9
J11
306-00303
A7r Aluminum Rail Handle
1
C10
302-00277
A7r & A7u Spring Washer SW8
9
J12
302-00270
A7r Round Head Screw M6*1*12
2
C11
302-00245
A7r & A7u Hex Screw M6*1.25*50
4
J13
313-00077
A7r Lower Heard Rate Wire
1
C12
302-00252
A7r & A7u Insert Nut M10*1.5
4
K1
323-00162
A7r Seat Shuttle Assembly
1
D1
323-00161
A7r & A7u Rear Stabilizer Assembly
1
K2
302-00306
A7r Oval Head Allen Bolt
2
F1
302-00258
A7r & A7u Round Head Allen Bolt M5*0.8*12
3
K3
302-00277
A7r Spring Washer
4
A7r Parts List Rev C
