Architectural and Engineering
Specifications
The smoke alarm shall be Kidde unit 0910/0910CA or approved
equal. It shall be powered by a non-replaceable lithium battery with a
10-year life. The lithium battery shall be sealed in the unit to prevent
removal and/or tampering. The unit shall incorporate an ionization
sensor with nominal sensitivity of 0.99%/ft (.87%/ft for unit 0910CA).
The temperature operating range shall be between 40°F and 100°F
(4°C and 38°C) and the humidity operating range shall be 5% - 95%
relative humidity.
The smoke alarm can be installed on the surface of any wall or ceil-
ing following the UL/Manufacturer’s approved placement guidelines.
The alarm shall incorporate an automatic activation feature that will
activate the unit as soon as it is attached to the mounting bracket, no
other steps are involved. The alarm shall provide optional tamper resis-
tance that locks the unit to the mounting bracket and deters removal
of the unit from the wall or ceiling.
The alarm shall include a test button that will simulate a fire condition
and cause the unit to go into alarm. This sequence tests the unit’s
electronics to ensure proper operation.
The unit shall include a piezoelectric horn that is rated at 85 decibels
at 10 feet. The unit shall include the Smart Hush
TM feature that silences
the unit for approximately 7 minutes if a nuisance condition occurs.
The red LED will illuminate for 1.5 seconds every 8 seconds and will
automatically reset itself. If the alarm is in the Hush mode and the
condition that triggered the alarm persists, the alarm shall sound again
to signal potential danger despite its presence in Hush Mode.The unit
shall incorporate one red LED to indicate the alarm’s current status
and mode of operation. The LED will indicate one of four modes:
Standby Mode: LED will flash every 40-45 seconds to indicate
the unit is operating correctly
Alarm Mode: LED will flash every 1.5 seconds to indicate the
unit is alarming and will be accompanied by the
horn sounding
Hush Mode: LED will illuminate for 1.5 seconds every 8
seconds to indicate the unit is temporarily silenced
Memory Set Mode: If Alarm Memory has been set, the LED will
flash rapidly when the test button is pressed.
Sealed Battery Unit
Smoke Alarm with Hush TM
Model 0910
Part Number 900-0136
Technical Specifications
Model: 0910
UPC Number: 0-47871-90136-4
Power Source: Three, 3V Lithium batteries
Sensor: Ionization
Audio Alarm: 85dB at 10ft
Temperature Range: 40˚F (4.4˚C) to 100˚F (37.8˚C)
Humidity Range:
5%-95% relative humidity (RH)
Size: 5.6” in diameter x 1.55” depth
Weight: 1.5lbs
Interconnects: No
LED: Four modes of operation
Warranty: 10 year limited
The unit shall include an End of Life Alert which is indicates the
alarm needs to be replaced. The unit will “chirp” once every 30
seconds to notify the user. The unit shall have a deactivation switch
to disable it and make it safe for disposal. The unit shall at a mini-
mum meet the requirements of UL217, NFPA72, (chapter 11 2002
edition) The State of California Fire Marshall, NFPA101 (One and
two family dwellings) Federal Housing Authority (FHA), Housing
and Urban Development (HUD).
Ordering Information
Clamshell UPC: 0 47871 90136 4
Part Dimensions Case/ Layers/ Skid
Number I 2 of 5 Pack Quantity (w x d x h inches) Weight Skid Skid Weight
900-0136 N/A N/A Individual 7.25 x 1.75 x 11 1 lbs N/A ----- N/A
900-0136-003 100 47871 90136-1 PDQ (3 units) 7.75 x 6 x 11.75 3 lbs 108 ----- 972 lbs
900-0136-020 200 47871 90136-8 Master Pack (20 units) 16 x 24 x 12 20 lbs 12 ----- 240 lbs
21007387 400 47871 90136-2 4pc Tray and Lid 7.75 x 9.25 x 11.75 4 lbs 75 300 lbs
5.6" 1.55"
1016 Corporate Park Drive
Mebane NC 27302
1-800-880-6788
www.Kidde.com
Distributed by:
revised 10/2008
