FRONT

FM/AM antenna input

1

Fuse (10A)

24

2

KENWOOD disc changer control input

Wiring harness

25

To connect the Disc changer,
consult your Disc changer manual.

3

Connecting Wires to Terminals

Front right
output (Red)

1

Front left
output (White)

1

Rear left output (White)/
Non-fading (Sub woofer) left output (White)

1

Rear right output (White)/
Non-fading (Sub woofer) right output (Red)

1
