KF-AAB Parts list Rev B
Ref # Part # description Qty
1 3-0087 FRAME, UPRIGHT KF-AAB 1
3-00877 MAIN FRAME, KF-AAB 1
3 8-0000 SEAT PAD, TOP KF-AAB 1
4 8-0001 SEAT PAD, LOWER KPS-AAB 1
5 3-00878 FRONT BASE, KF-45 1
19-00537 FOAM TUBE, KF SERIES
7 0-00397 END CAP, 0 KF-AAB
8 0-00389 HAND GRIP, KF-45/KF-AAB 1
9 0-00118 ENDCAP W/WHEEL 0
10 0-00395 FOAM PADDING, 100XX180 KF SERIES 4
11 0-0039 EZ GLIDE SLEEVE, KF-AAB
1 0-00390 PLUG, ROLLER PAD TUBE CAP, KF SERIES 4
13 0-00398 PLASTIC SLEEVE, 50.8*7.-5 KF-AAB/KF-F 1
14 0-00399 PLUG, 50.8X7. KF-AAB 1
15 10-0057 POP PIN (LOCKING), KF-45/KF-AAB 1
1 0-0034 SCREW, M10X80 BUTTON HEAD SOCKET CAP 1
17 0-0037 SCREW, M10X70 BUTTON HEAD SOCKET CAP 4
18 0-0038 SCREW, M10X95 BUTTON HEAD SOCKET CAP 1
19 0-003 WASHER, 11X3X 8
0 0-00091 NYLON NUT, M10
# 15-00094 MANUAL KF-AAB 1
