STEP 2

STEP 1

NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.

Connect Main Frame () to Front Base

(5) by securing with Bolt (18), Washers

(19) and Nylon Lock Nut (0). Place EZ

Slides (11) into Main Frame ().

Slide Upright Frame (1) into Main Frame

(). Make sure that adjustment holes

in Upright Frame (1) face toward Main

Frame ().

Slide Bolt (1) into Upright Frame (1)

and secure with Washers (19) and

Nylon Lock Nut (0). This bolt will keep

the Main Frame () connected to the

Upright Frame (1) during adjustments.
