Assembly
6
Right Fender
Left Fender
Left Upright
Right Upright
Left Fender
Left Upright
Console Harness
Figure 1
Step 1
Place the left and right uprights
tube through the holes in the left
and right fenders.
Figure 1
Figure 2 Figure 2
Step 1
Slide the fenders up the upright
assembly and pull the console har-
ness through the hole in bottom of
the left upright tube.
Assembly requires the included allen wrench.
Do not plug in the power cord until all assembly steps are completed.
