Assembly
5
The Keys 4500T Treadmill will require assembly before operating. After opening the box, remove any pack-
ing material from the treadmill.
Do not throw away any packing materials until the unit is working properly.
Place the base on a clean, level surface. Make sure the electrical cord will easily reach an electrical outlet.
Locate the hardware pack and identify the following parts required for assembly.
Parts List:
Base
Console
Left Upright
Right Upright
Safety Key
Allen Wrench
Manual
Left Junction Box
Right Junction Box
Right Fender Left Fender
Philip Screw M6*12
6 pcs
Philip Screw ST4.2*13
6 pcs
Washer 9*22*2
12 pcs
Allen Bolt M8*15
12 pcs
1. Owner’s Manual
2. Base Assembly
3. Console Assembly
4. Left and Right Upright
5. Left and Right Fender
6. Safety Key (Reed Switch)
7. Console Assembly 8. Left and Right Junction Box
9. Philip Screw M6 *12 (Qty 6)
10. Allen Bolt M8 *15 (Qty 12)
11. Washer 9*22*2 (Qty 12)
12. Allen Wrench
