Parts list 220v – Keys Fitness 4500T User Manual
Page 26
Parts List 220V
26
Ref #
Part #
Description
Qty
Ref #
Part #
Description
Qty
1
419-00023
CONSOLE PLATE ALLIANCE 2002, 19-0201
1
67
402-00035
SCREW ST2.9*6.5
19
2
423-00033
LEFT UPRIGHT SILVER, 4500T/5500T
1
68
402-00035
SCREW ST2.9*6.5
4
3
423-00034
RIGHT UPRIGHT SILVER, 4500T/5500T
1
69
402-00107
CHAMFER BOLT ST4.8*25
4
4
423-00023
DECK FRAME
1
70
402-00023
NYLON LOCK NUT M10
6
5
423-00035
BASE FRAME SILVER, 4500T/5500T
1
71
402-00021
NYLON LOCK NUT M8
3
6
423-00036
ELEVATION FRAME SILVER, 4500/5500T
1
72
402-00108
JAM NUT M8
4
7
423-00037
ELEVATION SUPPORT SILVER, 4500/5500T
1
73
402-00026
WASHER 9*16*1.6 (mm)
3
8
419-00022
LINKAGE PLATE SILVER, 4500/5500T
2
74
402-00082
WASHER 9*22*2
8
9
404-00002
POLY V-BELT 200J8(508J8)
1
75
402-00109
WASHER 11*23*2
4
10
404-00012
WALKBELT, 20X56 NW BELT, 4500T
1
76
402-00110
SCREW 8-32-3/8
1
11
403-00007
WALKING BOARD, 20*56 NW ORTHO
1
77
402-00111
SCREW 8-32-5/8
1
12
409-00007
FRONT ROLLER
1
78
402-00104
SHOULDER ALLEN BOLT M8*80
2
13
409-00008
REAR ROLLER
1
79
402-00113
GEAR WASHER D5
1
14
406-00091
MOTOR COVER
1
80
402-00079
SPRING WASHER 2.5MM
2
15
406-00115
LEFT FENDER SILVER, 4500T/5500T
1
81
402-00046
CLIP NUT
4
16
406-00116
RIGHT FENDER SILVER, 4500T/5500T
1
82
402-00048
PAN SPRING WASHER 10*19*0.25
4
21
419-00021
END CAP, LEFT SILVER, 45/5500T
1
83
402-00114
SHOULDER ALLEN BOLT M8*60
1
22
419-00020
END CAP, RIGHT SILVER, 45/5500T
1
84
402-00115
PHILIP SCREW ST3.5*13
4
23
406-00072
FRONT WHEEL
2
85
402-00116
CHAMFER BOLT ST4.8*16
3
24
406-00044
REAR WHEEL
4
86
402-00034
ALLEN WRENCH 110*75*6
1
25
419-00012
REAR WHEEL SHAFT
2
87
413-00012
ENCODER HARNESS
1
26
406-00073
ELEVATION WHEEL
4
88a 413-00013
CONSOLE HARNESS A
1
27
406-00074
TOP HANDLE
2
88b 413-00025
CONSOLE HARNESS B
1
28
406-00075
BOTTOM HANDLE
2
88c 413-00026
CONSOLE HARNESS C
1
29
410-00020
PULSE RECEPTACLE PLATE - TOP
2
89a 413-00023
SPD AND INCL HARNESS B
2
30
410-00021
PULSE RECEPTACLE PLATE - BOTTOM
2
89b 413-00021
SPD AND INCL HARNESS A
2
31
406-00076
DOME END CAP 35mm
2
90a 413-00022
EKG HARNESS A
1
32
405-00010
EXTRUSION, BOLT ON, INRAY
2
90b 413-00024
EKG HARNESS B
1
33
406-00092
BOTTOM SHEET, HT75/85t
1
91
413-00017
JUMPER WIRE
1
34
406-00078
BUMPER
8
92
413-00034
POWER CORD, 220 V
1
35
410-00036
LATCH SET
1
93
408-00028
CIRCUIT BREAKER, 220V
1
36
419-00014
STOPPER BRACKET
1
94
408-00024
ENCODER
1
37
402-00103
METAL BUSHING
2
95
408-00022
FUSE
1
38
419-00015
BOLT SHAFT A
2
96
408-00023
FUSE
1
39
419-00016
BOLT SHAFT B
2
97
408-00005
FERRITE CORE
1
40
406-00079
BASE BUMPER
6
98
407-00006
SPEED INCLINE PCB, 07-0080
2
41
419-00019
BELT GUIDE BRACKET, HT95T/4500T/5500T
2
99
413-00016
REED SWITCH
1
42
410-00041
SOFT DROP SHOCK
1
100 413-00031
TEL-LINE, HT95T
1
43
406-00045
ADJUST SUPPORT
2
101 406-00114
PLASTIC SUPPORT CLIP, 4500T/5500T
4
44
406-00080
CORD SPACER
4
102 407-00021
CONSOLE PCB, 07-0089, 5 LCD BLUE
1
45
406-00057
POWER CORD SPACER
1
103 406-00117
PCB MEMBRANE, 08-164, 4500T
1
46
419-00009
REED SWITCH PLATE
1
104 407-00018
EKG MODULE, 07-0092
1
49
406-00111
CONSOLE ALLIANCE WRAP, 06-0175, SILVER
1
105 402-00090
KILL SWITCH MAGNET
1
50
406-00118
INSERT LCD FOR CONSOLE, 06-0141
1
106 412-00015
MOTOR, 220V 12-0062
1
51
406-00112
LEFT JUNCTION BOX, 4500T/5500T
1
107 406-00090
FAN FOR MOTOR
1
52
406-00113
RIGH JUNCTION BOX, 4500T/5500T
1
108 408-00027
TRANSFORMER, HT95T/4500T/5500T
1
53
402-00135
WASHER, DISHING
10
109 407-00023
MOTOR CONTROLLER, 08-0159 220V
1
54
406-00109
BUMPER
2
110 412-00011
ACTUATOR, 220V, MS4VB
1
55
402-00008
HEX BOLT M10*60
1
111 414-00009
SPEED DECAL, 14-0520
1
56
402-00009
HEX BOLT M10*45
1
112 414-00008
INCLINE DECAL, 14-0521
1
57
402-00010
ALLEN BOLT M8*50
2
113 414-00043
CONSOLE OVERLAY, IN-079, 4500T
1
58
402-00011
ALLEN BOLT M8*15
8
114 414-00041
DECAL KEYS UPRIGHT, 14-0528
1
59
402-00105
ALLEN BOLT M10*15
4
115 414-00042
KEYS MOTOR COVER DECAL, 14-0523
1
60
402-00106
CHAMFER BOLT M6*25
8
116 414-00044
LABEL ENDCAP, MODEL 4500T, IN-096
2
61
402-00018
PHILIP SCREW M6*12
11
117 414-00002
SAFETY KEY DECAL
1
62
402-00031
PHILIP SCREW ST4.2*13
12
118 414-00036
SERIAL LABEL, INRAY
1
63
402-00067
PHILIP SCREW ST4.2*16
41
119 414-00045
LABEL, HP FOR 4500T
1
64
402-00031
PHILIP SCREW ST4.2*13
6
120 415-00016
OWNER'S MANUAL 4500T
1
65
402-00031
PHILIP SCREW ST4.2*13
4
121* 408-00030
RECEPTACLE, 2006 CE INRAY TREADMILLS
1
66
402-00031
PHILIP SCREW ST4.2*13
26
122* 408-00031
INDUCTOR, 2006 CE INRAY TREADMILLS
1
4500t CE (220v) Treadmill Parts List Rev A
