Figure 1 The DVD Standard Front Panel
Power
1 Power
Button
2 Power
LED
3
Stand-by LED
4 Infrared
Sensor
Menu and Setup
Functions
16 Directional
Buttons
17 Enter
Button
18 Menu
Button
19 Setup
Button
Disc Functions
5 Repeat
Button
6 Pause
Button
7 Stop
Button
8 Play
Button
9 Track Forward Button
10 Track Back Button
11
Search Forward Button
12 Search Back Button
13 Open/Close
Button
14 Disc
Transport
15 Front Panel Display
