CO Time
The CO Time (Continuous Operation Time) details
how long an appliance can be operated without
the motor overheat-ing and becoming damaged.
After the appliance has run for this period it must be
switched off until the motor has cooled itself down.
Appliance description
q Direction switch
w Start switch
e Power cable with power plug
r Motor unit
t Threaded rod
y Pusher
u Container
i Nozzle adapter with seal
o Nozzles
a Adapter lock
s Lock ring
d Motif discs
Before the first use
Take the Biscuit Shaper and all accessories from the
packaging and remove all packaging material.
Clean all of the components as described in the section
„Cleaning and care“.
Assembling the Biscuit Shaper
Note:
Remove the power plug e from the wall socket be-
fore assembling accessories.
Inserting the threaded rod with pusher
1. Place the end of the threaded rod t in the
motor unit r . Ensure that the pins inside the
motor unit r engage with the guide rails on the
threaded rod t .
2. Slide the threaded rod t with the pusher y as
far as it will go into the motor unit r .
Assembling the container
Note:
The container u must be fitted, otherwise the
Biscuit Shaper will not function!
1. Slide the container u over the pusher y such
that the guide rails inside the container u enga-
ge in the in notches on the pusher y .
2. Place the container u on the motor unit r so
that the arrow on the container u points to the
open lock on the motor unit r .
3. Turn the container u until the arrow on the
container points to the closed lock on the
motor unit r .
4. Insert the power plug e into a wall socket.
5. Place the direction switch q onto the arrow
pointing downwards .
6. Press and hold the start button w until the
pusher y has returned itself to the MAX
marking.
7. Remove the power plug e from the wall socket.
Assembling motif discs
When the pusher y and container u are
assembled:
1. Select the desire motif disc
d .
2. Place the motif disc d into the lock ring s .
3. Place the lock ring s with the motif disc d onto
the container u .
4. Turn the lock ring s in the direction of the arrow
until it engages .
