PARTS LIST
MODEL NO.: IS2336SQ
IS2342SQ
KEY NO. DESCRIPTION MODEL /SIZE PART NO.
1 Power Cord C1-0406-0120-01
2 6” Round Plastic Exhaust C1-0505-0001
3 Round Head Screw (TS 4 x 6) C1-0708-0006
4 Hood Roof B101-1242-13
IS2336SQ B101-1236-02 5 Hood Casing
IS2342SQ B101-1242-02
6 Transformer Bracket C1-0202-1242
7 Transformer (Light) C1-0402-0120-40
8 Transformer Bracket Screw (3/16” x 3/8”) C1-0707-0001
9 Halogen Light (12V 20W Max.) C1-0403-0101
10 Transformer Support (Light) C1-0201-1242
11 Screw (3/16” x 3/8”) C1-0707-0001
12 Capacitor C1-0401-0120-01A
13 Round Head Screw (TS 4 x 6) C1-0707-0001
14 Processor Board Box C1-0501-0102
15 Processor Board C1-0404-0401-B
16 Flat Head Screw (M 2 x 8) C1-0704-0003
Air Chamber
Air Chamber (Top)
C1-0102-1242
17
A
B
Air Chamber (Side) C1-0101-1242
18 Motor (Left) C1-0301-0120-07A
19 Motor (Right) C1-0301-0120-08A
20 Turbine Impeller (Left) C1-0251-0092-01
21 Turbine Impeller (Right) C1-0251-0092-02
22 Oil Tunnel C1-0502-0201
IS2336SQ B101-1236-09 23 Bottom Casing
IS2342SQ B101-1242-09
24 Impeller Plastic Cover C1-0251-0001
25 Motor Position Screw (3/16” x 5/8”) C1-0703-0001
26 Bottom Casing Screw (3/16” x 5/8”) C1-0704-0001
27 Transformer Screw (3/16” x 3/8”) C1-0707-0001
28 Control Board C1-0404-0401-A
29 Control Unit C1-0501-0101
30 Round Head Screw (TS 1/8” x 3/8”) C1-0708-0003
31 Transformer (Motor) C1-0402-0120-40
