Assembly
8
Step 5:
Attach left inside handle cover and left
outside handle cover to left upright using
Phillips screw ST4.2x13 (Qty. 3) as shown in
Figure 5.
Repeat assembly step for right side handle
covers.
Figure 5
Figure 6
Step 6:
Tighten all Allen bolts (Qty. 8) installed
in Step 3. Note: Move the fenders up to
access the Allen bolts.
Next, attach both left and right fend-
ers to base using Phillips screws ST4.2x13
(Qty. 2) and Phillips screws M6x12
(Qty. 2).
Move the treadmill to its final location
(see section titled “Moving Instructions”).
Adjust the leveler feet so that the treadmill
does not wobble while in use.
PHILLIPS SCREW
PHILLIPS SCREW
FENDER LEVELER
FOOT
