Assembly
6
Assembly requires the included allen
wrench.
Do not plug in the power cord until all
assembly steps are completed.
Step 1:
Place the left and right fenders through
the tube of the left and right uprights as
shown in Figure 1.
Figure 1
Figure 2
Step 2:
Slide the fenders up the upright assembly
and pull the console harness through the
hole in bottom of the left upright tube as
shown in Figure 2.
CONSOLE HARNESS
FENDERS
UPRIGHTS
