UNCRATING 5
No. Part Name Qty Remarks
1 Handlebar with Grip 1
Handlebar Clamp 2
Clamp Bolt, Socket 4 D = 10, L = 23
Plastic Plug, Clamp Bolt 4 Large
Throttle Grip 1
Clamp, Master Cylinder 2
Clamp Bolt, Master Cylinder, Socket 4 D = 6, L = 20
Plastic Plug, Clamp Bolt 4 Small
Plastic Clamp, Wiring and Hose 4 L = 88.5
Screw, Switch Housing, LH & RH 4 D = 5, L = 25
Rear View Mirror, LH & RH 2
2 Front Wheel 1
Axle Collar, LH & RH 2 L = 46.5
Front Fender with Brace 1
Socket Bolt, Front Fender 4 D = 8, L = 35
3 For US and CN Models
Brake Hose Clamp, LH & RH 2
Grommet, Brake Hose 2
Front Reflector, LH & RH 2
Flanged Nut, Reflector 2 D = 5
4 For other than US and CN Models
Brake Hose Clamp, LH & RH 2
Grommet, Brake Hose 2
5 Front Left Footboard Assembly 1
Flanged Bolt, Front Footboard, LH 2 D = 10, L = 30
Front Guard, LH & RH 2
Flanged Bolt, Front Guard 2 D = 10, L = 25
Warning Label, Front Left Guard 1 US and CN Models Only
Front Shift Pedal 1
Rear Shift Pedal 1
Flanged Bolt, Front and Rear Shift Pedals 2 D = 8, L = 25
6 Rear Guard, LH & RH 2
Flanged Bolt with Washer, Rear Guard, Upper 2 D = 8, L = 30
Socket Bolt, Rear Guard, Lower 2 D = 10, L = 50
Plastic Plug, Socket Bolt, Rear Guard 2 Large
Flanged Bolt, Rear Guard 4 D = 8, L = 35
Cap Nut, Rear Guard 4 D = 8
Helmet Lock 2 Located in the left side cover.
Screw with Non-permanent locking agent, Helmet Lock 2 D = 5, L = 12
Warning Label, Rear Left Guard
1 US and CN Models Only
7 Backrest Pad 1
Backrest Frame 1
Cover with Mark, Backrest 1
Cap Nut, Cover 4 D = 6
Bolt, Backrest Frame 4 D = 8, L = 50
Nut, Backrest Frame 4 D = 8
