Konica Minolta Dimage V - Manual (Page 23)

43
PHOTOGRAPHING YOURSELF LENS EXTENSION CABLE
42
Rotate the lens unit 90°
backwards until it stops.
• The image on the monitor will be
right-side-up, but backwards (as if
you are looking in a mirror).
• If the image appears up-side down
on the monitor, the lens unit has
not been fully rotated to -90°.
Frame yourself in the LCD
monitor, then press the
shutter-release button.
The Dimâge V lens unit rotates from +90° to -90°. This function
allows you to photograph yourself while looking at the LCD monitor. With the Lens Extension Cable LS-V100 the lens unit can be
detached from the camera and used to photograph from a variety of
angles.
Turn the camera off before attaching or detaching the lens unit.
DETACHING THE LENS UNIT
Slide the lens unit release
lever in the direction
indicated. Slide the lens
unit up and then away
from the camera.
Detach the lens unit.
Match-up the two notches
on the camera with the
two notches on the lens
extension cable. Gently
put them together as
shown.
• Note that only one end of the
cable has two notches, the other
end has three.
ATTACHING THE LENS EXTENSION CABLE
Continued on next page.
