22

|

English

1

..........1

2

..........1

3

..........2

4

..........4

5

..........4

6

..........2

7

..........1

Accessories

Installation

Bracket

3

Tapping Screw

5

Semusu Screw

4

• Do not use your own screws. Use only the screws

provided. If you use the wrong screws, you could
damage the unit.

• Do not install the unit to an unatable place and a place

where it vibrates.

• You can mount the unit at any angle between the

regular horizontal position and the vertical position on
its back (0° through 90°). You cannot mount the unit with
the disc slot facing downwards, angled or upside down.

Installation using the Brackets

Installation using the velcro tapes

Velcro tape

6

Carpet

• If the fuse blows, first make sure that the wires have not

caused a short circuit, then replace the old fuse with one
with the same rating.
