-9-
DC Power Interface
Interface
Screw-type terminal block
1. Two pairs for power wire cascading
2. One pair for power failure relay output
DC Jack (-D6.3mm/+D2.0mm)
Operating Input Voltages +7V ~ +30V(+5%)
Power consumption 2.25W @+7.5VDC input
2.3W @+24VDC input
2.5W @+30VDC input
Basic Information
Conversion
Full wire speed
1000Mbps - 1,488,00pps at 64-byte packets
Packet Types Transparent and no modification for
- IEEE 802.3 standard packets
- IEEE 802.1Q VLAN tagged packets
Packet Length No limit
Mechanical
Dimension (base)
W 28mm x D 82mm x H 95mm
Housing Enclosed metal with no fan
Mounting Support DIN-rail mounting, Panel mounting
Weight 252g
Environmental
Operating Temperature
Typical -20 o C ~ 70 o C (model dependent)
Storage Temperature -20 o C ~ 85 o C
Relative Humidity 5% ~ 90%
