-8-
Twisted-Pair Interface (Copper Port)
Connector
Shielded RJ-45
Signal Compliance IEEE 802.3ab 1000BASE-T std.
Pin Assignments Auto MDI/MDI-X detection
Data Speed 1000Mbps
Duplex Mode Half-duplex or Full-duplex
Configuration Auto-negotiation support
Cable Types Category 5 or higher UTP
Link Distance Up to 100 meters
Fiber Optic Interface (Fiber Port)
Signal Compliance
IEEE 802.3z 1000BASE-SX/LX std.
Connector SFP for pluggable fiber transceiver
Data Speed 1000Mbps
Duplex Mode Full duplex
Cable Types MMF - 50/125, 62.5/125
SMF - 9/125
Link Distance MMF up to 500m
SMF -model dependent
Eye Safety compliance IEC825 Class 1
Refer to Appendix for detailed optical specifications.
LED Indicators
LED
DISPLAY STATE INTERPRETATION
PWR Power status ON Power on
OFF Power off
SFP SFP slot status ON SFP transceiver is installed.
OFF No SFP transceiver is installed.
LINK Link status ON Copper-fiber link up
OFF Copper-fiber link down
BLINK Copper-fiber link with data traffic
OL Optical status ON Fiber port optical signal detected
OFF Fiber port no optical signal
