L LO OC CA AT TIIO ON N
Position the Arc Welder on a secure level surface in a dry location where there is
free circulation of clean air. Ensure all air passages are clean and free of obstruc-
tions. Blocked air passages can cause the Arc Welder to overheat.
U UN NP PA AC CK KIIN NG G
All welding accessories (except for the welding helmet and leather gloves) are
stored inside the wire feed compartment on the top of the welder. Lift and remove
the wire feed cover to find the handle, work clamp, grounding cable, and wire spool.
A AS SS SE EM MB BL LY Y
D Diisscco on nn neecctt tth hee p po ow weerr p pllu ug g ffrro om m tth hee A AC C
p po ow weerr sso ou urrccee b beeffo orree aan nyy aasssseem mb bllyy,, aad djju ussttm meen nttss,, o orr
aad dd diin ng g//rreem mo ovviin ng g aacccceesssso orriieess.. Following this preventative step
reduces the risk of the Arc Welder coming on accidentally and the
risk of damage to the workpiece and injury to the operator.
A AT TT TA AC CH H H HA AN ND DL LE E::
1. Place the handle (1) on top of the cover.
2. Secure the handle, using the screws and washers (2).
10
9
FFU UN NC CT TIIO ON NA AL L D DE ES SC CR RIIP PT TIIO ON N
C CO ON NT TR RO OL LS S A AN ND D C CO OM MP PO ON NE EN NT TS S::
1. Welder
2. Torch
3. Overload Indicator
4. Power Switch
5. Wire Speed Control
6. Amperage Selection Switch
7. Ground Cable
8. Power Cord
9. Helmet
T Th hiiss aarrcc w weelld deerr rreeq qu uiirreess aa d deed diiccaatteed d 1 12 20 0V V//6 60 0 H Hzz --
3 30 0 A AM MP P cciirrccu uiitt aatt ““M Maaxx”” aam mp peerraag gee sseettttiin ng g o orr 2 20 0 A Am mp p cciirrccu uiitt aatt ““M Miin n””
aam mp peerraag gee sseettttiin ng g tto o ffu un nccttiio on n p prro op peerrllyy.. Do not run other lights, appli-
ances, or tools on this circuit while the Arc Welder is in operation. Failure
to comply with this CAUTION will result in tripped circuit breakers and/or
blown fuses.
A AC CC CE ES SS SO OR RIIE ES S::
10. Wire Reel Washer and Wing Nut
11. Flux Core Wire
12. Wire Brush/Hammer
13. Contact Tip
14. Leather Welding Gloves
15. Wrench
2
1
2
3
1
2
4
5
6
9
15
13
7
11
10
8
12
14
