AUDIO OUT CABLE WIRING
-22-
Alinco DX77
Kenwood
TS130/140
TS430/440
TS850/TS870
TS930/940/950
SG2020
K2
Japan Radio
JST-135
JST-245
Yaesu
FT990/ft992
FT1000MP/M-V
+ Mic
PTT
GND
ICOM
735
745/746
756/756 PRO
775
781
KACHINA
Gnd
PTT
+ Mic
Gnd
Gnd
PTT
PTT
- Mic
- Mic
- Mic
- Mic
+ Mic
+ Mic
8 Pin Mic Connector Pin 8
8 Pin Mic Connector Pin 5
8 Pin Mic Connector Pin 3
8 Pin Mic Connector Pin 1
8 Pin Mic Connector Pin 1
8 Pin Mic Connector Pin 7
8 Pin Mic Connector Pin 5
8 Pin Mic Connector Pin 6
Shield of Cable
Shield of Cable
Shield of Cable
Shield of Cable
8 Pin Mic Connector Pin 2
8 Pin Mic Connector Pin 2
8 Pin Mic Connector Pin 6
8 Pin Mic Connector Pin 7
8 Pin Mic Connector Pin 7
8 Pin Mic Connector Pin 1
8 Pin Mic Connector Pin 8
Yaesu
FT102
FT747/757/767
FT847
FT1000/1000D
+ Mic
PTT
GND
- Mic
8 Pin Mic Connector Pin 6
8 Pin Mic Connector Pin 7
Shield of Cable
8 Pin Mic Connector Pin 8
ICOM BALANCED
MODULATOR
746
756 / 756 PRO
775
781
910H
+ Mic
PTT
GND
- Mic
8 Pin DIN Connector Pin 3
8 Pin DIN Connector Pin 2
Shield of Cable
8 Pin DIN Connector Pin 4
DIN connectors shown on the side to be soldered
DO NOT SOLDER TO SHIELD OF DIN
