AUDIO OUT CABLE WIRING
DIN connectors shown on the side to be soldered
DO NOT SOLDER TO SHIELD OF DIN
HI-Z
LOW Z TRS BALANCED OUTPUT
LOW Z UNBALNCED 1/4”
MONO CONNECTOR
LOW Z Single channel Input
to Computer Sound Card
HI Z TRS BALANCED OUTPUT
LOW-Z
LOW-Z
LOW-Z
HI-Z
LOW-Z
- Audio
- Audio
- Audio
- Audio
+ Audio
+ Audio
+ Audio
+ Audio
GND
GND
GND
GND
Shield of Cable
Shield of Cable
Shield of Cable
Shield of Cable
LOW Z XLR BALANCED OUTPUT
HI-Z XLR BALANCED OUTPUT
- Audio
- Audio
+ Audio
+ HI-Z Audio
GND
GND
Shield of Cable
Shield of Cable
1 2
3
1 2
3
-24-
