PARTS LIST
MODEL NO.: CH9630SQB
CH9636SQB
CH9642SQB
CH9648SQB
Body Components
NO. DESCRIPTION MODEL/SIZE PART NO.
1 Screws (3/16” x 3/8”) CH196-1
2 Hood Casing CH196-2
3 Hood-Mounting Bracket CH196-3
4 Screws (3/16” x 3/8”) CH196-1
5 Stainless Steel Oil Tunnel CH196-4
6 Blower Assembly CH196-5
7 Halogen Light Panel CH196-6
8 Gasket CH196-7
9 Screws (3/16” x 3/8”) CH196-1
10 Halogen Light CH196-9
11 Gasket CH196-8
12 Stainless Steel Spacer
CH9630SQB CH196-10
CH9636SQB CH196-11
CH9642SQB CH196-12
A
B
C
D
CH9648SQB CH196-18
13 Baffle Filter CH196-13
14 Baffle Handle CH196-14
15 Electrical Assembly CH196-15
16 Screws (3/16” x 3/8”) CH196-1
17 Wiring Box CH196-16
18 Screws (3/16” x 3/8”) CH196-1
19 Switch Assembly CH196-17
20 Screws (3/16” x 3/8”) CH196-1
21 Board CH196-18
22 Screws (3/16” x 3/8”) CH196-1
