13
PARTS LIST
MODEL NO.: CH8136SQB
NO. DESCRIPTION MODEL / SIZE PART NO.
1 Duct Cover Bracket
CH0061
2 Inner Duct Cover
CH0595
3 Outer Duct Cover
CH0596
4 6-1/4” Plastic Damper
CY0187
5 Rubber Seal
CH0539
6 Screws (3/16” X 3/8”)
G3215
7 Back Casing
CH0592
8 Blower Assembly
9 Screws (3/16” X 3/8”)
G3398
10 Brackets
CH0059
11 Hood Frame
CH0040
12 Left / Right Side Trim
CY0619/CY0620
13 Front Trim
CH0044
14 Baffle Filters
CH0594
15 Bottom Casing
CH0591
16 Halogen Lights
CY03341
17 Baffle Knobs
CY0324
18 Electrical Box
CY04751
19 Power Board
CY0278
20 Capacitor
01475
21 Electrical Box Cover
CY0475
22 Setup Board
CH0048
