DVB-T indoor antenna BZD 30
34
DVB-T indoor antenna BZD 30
The antenna's reception range is 174-230 MHz in the VHF band
and 470-862 MHz in the UHF band. As the BZD 30 is virtually
omni-directional, no special alignment is required.
Depending on the mode of installation, both vertical and
horizontal polarisation can be received. The remote feed
(5 V/30 mA) is provided via the antenna output from the
connected DVB-T receiver, e.g. Kathrein UFD 570/S or
KATHREIN Euroline  UFE 370/S. The antenna offers an
extremely low noise figure, and also features a filter to block
GSM interference.
Its stylish design and compact size (140 x 195 mm) means the
antenna will be a space-saving and attractive enhancement to
any interior decor.
The supplied accessories include a pedestal for ease of
installation, a wall bracket with fixings, and a 2 metre connecting
cable.
